什么是AOP?
(1)面向切面编程(方面),利用AOP可以对业务逻辑的各个部分进行隔离,从而使得业务逻辑各部分之间的耦合度降低,提高程序的可重用性,同时提高开发效率
(2)不修改源代码方式,在主干功能里添加新功能
AOP底层使用动态代理
(1)有两种的动态代理
- 有接口的情况,使用JDK动态代理
- 没有接口的情况,使用CGLIB动态代理
AOP(JDK动态代理)
使用JDK动态代理,使用Proxy
类里面的方法创建代理对象
调用newProxyInstance方法
方法里面有三个参数:
第一参数,类加载器
第二参数,增强方法所在的类,这个类实现的接口,支持多个接口
第三参数,实现这个接口InnovationHandler,创建代理对象,写增强的方法
编写JDK动态代理代码
(1)创建接口,定义方法
1
2
3
4public interface UserDao {
public int add(int a,int b);
public String update(String id);
}(2)创建接口实现类
1
2
3
4
5
6
7
8
9
10
11
12
13
14public class UserDaoImpl implements UserDao {
public int add(int a, int b) {
System.out.println("add方法执行了.....");
return a+b;
}
public String update(String id) {
System.out.println("update方法执行了.....");
return id;
}
}(3)使用Proxy类
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42public class JDKProxy {
public static void main(String[] args) {
//创建接口实现类代理对象
Class[] interfaces = {UserDao.class};
// Proxy.newProxyInstance(JDKProxy.class.getClassLoader(), interfaces, new InvocationHandler() {
// @Override
// public Object invoke(Object proxy, Method method, Object[] args) throws Throwable {
// return null;
// }
// });
UserDaoImpl userDao = new UserDaoImpl();
UserDao dao = (UserDao)Proxy.newProxyInstance(JDKProxy.class.getClassLoader(), interfaces, new UserDaoProxy(userDao));
int result = dao.add(1, 2);
System.out.println("result:"+result);
}
}
//创建代理对象代码
class UserDaoProxy implements InvocationHandler {
//1 把创建的是谁的代理对象,把谁传递过来
//有参数构造传递
private Object obj;
public UserDaoProxy(Object obj) {
this.obj = obj;
}
//增强的逻辑
public Object invoke(Object proxy, Method method, Object[] args) throws Throwable {
//方法之前
System.out.println("方法之前执行...."+method.getName()+" :传递的参数..."+ Arrays.toString(args));
//被增强的方法执行
Object res = method.invoke(obj, args);
//方法之后
System.out.println("方法之后执行...."+obj);
return res;
}
}
AOP(术语)
连接点
类里面哪些方法可以被增强,这些方法称为连接点
切入点
实际被真正增强的方法,称为切入点
通知(增强)
(1)实际增强的逻辑部分称为通知(增强)
(2)通知有多种类型
- 前置通知
- 后置通知
- 环绕通知
- 异常通知
- 最终通知(类似与 try catch里的finally)
切面
是动作上的操作
(1)把通知应用到切入点的过程
AOP操作准备
Spring框架中,一般都是基于AspectJ实现AOP操作
什么是AspectJ
不是Spring组成部分,独立AOP框架,一般把AspectJ和Spring框架一起使用,完成AOP操作
基于AspectJ实现AOP操作
- 基于XML配置文件
- 基于注解方式实现(常用)
在项目工程里面引入AOP相关依赖
切入点表达式
- 切入点表达式作用: 知道对哪个类里面的哪个方法进行增强
- 语法结构:
Execution([权限修饰符][返回类型][类全路径]][方法名称][全类名])
举例1: 对com.xyt.dao,BookDao类里面的add进行增强
execution(* com.xyt.dao.BookDao.add(..))
举例2: 对com.xyt.dao,BookDao类里面的所有方法进行增强
execution(* com.xyt.dao.BookDao.*(..))
举例3: 对com.xyt.dao类里面的所有方法进行增强
execution(* com.xyt.dao.*.*(..))
AOP操作(AspectJ注解)
创建类 在类里面定义方法
1
2
3
4
5public class User {
public void add() {
System.out.println("add.......");
}
}创建增强类
- 在增强类里创建方法,让不同方法代表不同的通知类型
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47//增强的类
//生成代理对象
public class UserProxy {
//相同切入点抽取
public void pointdemo() {
}
//前置通知
//@Before注解表示作为前置通知
public void before() {
System.out.println("before.........");
}
//后置通知(返回通知)
public void afterReturning() {
System.out.println("afterReturning.........");
}
//最终通知
public void after() {
System.out.println("after.........");
}
//异常通知
public void afterThrowing() {
System.out.println("afterThrowing.........");
}
//环绕通知
public void around(ProceedingJoinPoint proceedingJoinPoint) throws Throwable {
System.out.println("环绕之前.........");
//被增强的方法执行
proceedingJoinPoint.proceed();
System.out.println("环绕之后.........");
}
}进行通知的配置
(1)在Spring配置文件中开启注解扫描
1
2
3
4
5
6
7
8
9
10
11
12
13
14
<beans xmlns="http://www.springframework.org/schema/beans"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:context="http://www.springframework.org/schema/context"
xmlns:aop="http://www.springframework.org/schema/aop"
xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd
http://www.springframework.org/schema/context http://www.springframework.org/schema/context/spring-context.xsd
http://www.springframework.org/schema/aop http://www.springframework.org/schema/aop/spring-aop.xsd">
<!-- 开启注解扫描 -->
<context:component-scan base-package="com.atguigu.spring5.aopanno"></context:component-scan>
<!-- 开启Aspect生成代理对象-->
<aop:aspectj-autoproxy></aop:aspectj-autoproxy>
</beans>(2)使用注解创建User和UserProxy对象
1
2
3
4
5
6
7
8
9
10
11
12
13
public class User {
public void add() {
int i = 10/0;
System.out.println("add.......");
}
}
//生成代理对象
public class UserProxy {
//...
}(3)在增强类上面添加注解@Aspect
(4)在Spring配置文件中开启生成代理对象
1
2<!-- 开启Aspect生成代理对象-->
<aop:aspectj-autoproxy></aop:aspectj-autoproxy>(5)配置不同类型通知
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34//@Before注解表示作为前置通知
public void before() {
System.out.println("before.........");
}
//后置通知(返回通知)
public void afterReturning() {
System.out.println("afterReturning.........");
}
//最终通知
public void after() {
System.out.println("after.........");
}
//异常通知
public void afterThrowing() {
System.out.println("afterThrowing.........");
}
//环绕通知
public void around(ProceedingJoinPoint proceedingJoinPoint) throws Throwable {
System.out.println("环绕之前.........");
//被增强的方法执行
proceedingJoinPoint.proceed();
System.out.println("环绕之后.........");
}(6)编写测试类
1
2
3
4
5
6
7
8
9
10public class TestAop {
public void testAopAnno() {
ApplicationContext context =
new ClassPathXmlApplicationContext("bean1.xml");
User user = context.getBean("user", User.class);
user.add();
}
}(7)相同切入点抽取
1
2
3
4
5
6
7
8
9
10//相同切入点抽取
public void pointdemo() {
}
//@Before注解表示作为前置通知
public void before() {
System.out.println("before.........");
}(8)有多个增强类对同一个类进行增强
在增强类的上面添加注解 @order() 数字越小 优先级越高
1
2
3
4
5
6
7
8
9
10
public class PersonProxy {
//后置通知(返回通知)
public void afterReturning() {
System.out.println("Person Before.........");
}
}
AOP操作(配置文件) 了解
创建两个类,增强类,被增强类
1
2
3
4
5
6
7
8
9
10public class Book {
public void buy() {
System.out.println("buy.............");
}
}
public class BookProxy {
public void before() {
System.out.println("before.........");
}
}在Spring配置文件中创建两个类的对象
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
<beans xmlns="http://www.springframework.org/schema/beans"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:context="http://www.springframework.org/schema/context"
xmlns:aop="http://www.springframework.org/schema/aop"
xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd
http://www.springframework.org/schema/context http://www.springframework.org/schema/context/spring-context.xsd
http://www.springframework.org/schema/aop http://www.springframework.org/schema/aop/spring-aop.xsd">
<!--创建对象-->
<bean id="book" class="com.atguigu.spring5.aopxml.Book"></bean>
<bean id="bookProxy" class="com.atguigu.spring5.aopxml.BookProxy"></bean>
<!--配置aop增强-->
<aop:config>
<!--切入点-->
<aop:pointcut id="p" expression="execution(* com.atguigu.spring5.aopxml.Book.buy(..))"/>
<!--配置切面-->
<aop:aspect ref="bookProxy">
<!--增强作用在具体的方法上-->
<aop:before method="before" pointcut-ref="p"/>
</aop:aspect>
</aop:config>
</beans>测试类
1
2
3
4
5
6
7
public void testAopXml() {
ApplicationContext context =
new ClassPathXmlApplicationContext("bean2.xml");
Book book = context.getBean("book", Book.class);
book.buy();
}
全注解开发
不需要xml配置文件
